Google Pixel 8 Pro Earpiece Speaker Replacement Step-By-Step Guide

If you are thinking of changing your Google Pixel 8 Pro phone because the earpiece speaker is giving you a tough time? Wait! No need to change your flagship smartphone. We can fix it!
Basically this guide is specially made for those who are suffering from Google Pixel 8 Pro Earpiece speaker malfunctioning. However this malfunctioning is like cracking noise, distorted sound or no sound at all. So in such cases you need a Google Pixel 8 Pro Earpiece speaker replacement. Thus this step-by-step guide will show every step with clear explanations and visuals. Additionally we will give guidance about all the precautions, tips and tool guides for making your repair journey hassle-free. So let's start Google Pixel 8 Pro Earpiece Speaker Replacement.

Step #1. Gather Necessary Tools

Step #1. Gather Necessary Tools

Certainly before starting Google Pixel 8 Pro Earpiece Speaker Replacement you need to gather all the important tools. We are mentioning a list of tools that may be needed while repairing. So make sure you have these all.

  • You will need a Phillips head screwdriver.
  • Prepare plastic opening tools for the job.
  • Grab some spudgers to help with disassembly.
  • Don't forget a pair of tweezers for precision work.
  • Consider using a heat gun, hot plate, or even a hair dryer for stubborn parts.
  • Keep a suction tool handy for lifting components.
  • Get a genuine Google Pixel 8 Pro earpiece speaker replacement

However after collecting all these tools you should give second priority to the place where you are going to repair the Google Pixel Pixel 8 Pro earpiece speaker.

Make sure you can see well and have space to work. Keep your area clean and flat. Find a quiet spot near a power source for tools like a heat gun.

Step #2. Mark Opening Pick



Indeed it is important to mark your opening pick. This helps you be careful when removing the screen and internal parts. You will need about 4 to 5 opening picks to gently separate the screen from the frame. Be cautious not to push the opening pick too far to avoid damaging anything inside.

Remember the screen cable fits in the middle of the right edge of your Pixel 8 Pro. It is delicate so handle it with care to prevent damage. Take your time with this step to avoid accidents. Also watch out for the spring contacts around the edges of the phone. Bending one accidentally could cause serious damage.

However to mark your opening pick you can measure and mark 3mm with a marker. Alternatively, attach a coin to the pick using tape at the 3mm point to stop it from going in too far.

Step #3. Paper Google Pixel 8 Pro For Earpiece Speaker Replacement



Step #3. Paper Google Pixel 8 Pro For Earpiece Speaker Replacement

Now from here you will start your Google Pixel 8 PRO Earpiece Speaker Replacement. So first of all you have to check your phone’s charging. The charging should be less than 25%. Otherwise the battery could catch fire during disassembling the phone.

Another preparation is powering off Your Google Pixel 8 Pro. Here are the ways you can power off your Google Pixel 8 pro.

  • Press the power button and volume up button simultaneously.
  • Choose "Power off" from the options.
  • Your Google Pixel 8 Pro is now turned off.
  • To power it on again, press and hold the power button located on the side of the Google Pixel 8 Pro.

Step #4. Give Heat To All Sides of Your Google Pixel 8 Pro Phone

Step #4. Give Heat To All Sides of Your Google Pixel 8 Pro phone

Now use a heat gun to apply heat on the all edges of the Google Pixel 8 Pro. Here you can use a hot plate, hair dryer or even straighteners. But keep in mind that never give extreme heat or expose any spot to heat for more than 2 minutes.

However the screen sticks to the frame with glue and clips. When you heat the screen it gets softer and easier to remove.

Step #5. Place A suction Cup

Step #5. Place A suction Cup

Well after applying heat you need to apply a suction tool at the bottom edge of the screen. Pulling with the help of a suction tool you can easily create enough gap for inserting an opening pick.

Pull up the suction cup with steady force and don't try to dart. As you know the screen is tightly attached with adhesive and clips.

Step #6. Insert First Opening Pick

Step #6. Insert First Opening Pick
  • It's time to insert the first-opening pick into the gap.
  • Slide the opening pick to the right side.
  • However you can leave the opening picks at corners so the screen does not stick again.

To keep your phone safe don't push the pick in too deep while removing the screen. Remember these points.

  • The screen cable is near the middle of the left side. Handle it gently to avoid tearing.
  • Be careful around the spring contacts on the phone's edges to prevent bending them.

Step #7. Move The Opening Pick Around The Edges

Step #7. Move The Opening Pick Around The Edges
  • Now take another opening pick and insert it then slowly slide it at the bottom to loosen the glue.
  • After separating the adhesive from the bottom edge carefully slide it towards the upper right corner. It will lose the adhesive on the right side of the phone.
  • Leave the pick here to prevent sticking.
  • Put another pick under the bottom of the screen.
  • Slide it to the bottom left corner.
  • Leave it there to stop the adhesive from sticking again.
  • Now it's time to insert another opening pick for cutting the top edge glue.
  • Move the pick to cut the adhesive securely.

Step #8. Prevent Opening Pick Insertion More Than 3mm



Step #8. Prevent Opening Pick Insertion More Than 3mm

Indeed one most important thing is only to insert the opening pick 3mm. If you do this with your Google Pixel 8 Pro you will damage your phone's internal parts and connections.

Step #9. Cut Adhesive From All side



Step #9. Cut Adhesive From All side

At this stage you have all the adhesive around the screen edges.

Step #10. Separate the Screen

Step #10. Separate the Screen
  • Next use your first finger and thumb of both hands and lift the display screen of the Google Pixel 8 Pro.
  • If you feel the screen still adheres at any spot don't try peeling off. Give heat on that spot and cut the glue with the opening pick. Then easily try to lift the screen again.

Step #11. Prop Up The Google Pixel 8 Pro Screen

Step #11. Prop Up The Google Pixel 8 Pro Screen
Step #11. Prop Up The Google Pixel 8 Pro Screen2
  • Place a small support object like a box or stack of books on the left side of your phone. This will help hold up the screen while you work on it.
  • Gently lift the right edge of the screen as if opening a book's cover.
  • If the screen seems stuck use a tool to carefully separate any remaining adhesive around the edges.
  • Make sure the screen is propped up securely so you can reach the screen cable without pulling it too hard.

Step #12. Pry Up The Screen Cable Cover

Step #12. Pry Up The Screen Cable Cover
  • Next is taking a spudger to pry up the screen cable cover.
  • Gently pry it up and remove it with the help of your finger or using tweezers.

Step #13. Disconnect The Screen Cable Connection

Step #13. Disconnect The Screen Cable Connection
  • It's time to disconnect the screen cable.
  • Use a spudger's top point and insert it into the right corner of the press connector.
  • Gently pry up and disconnect the screen cable

Step #14. Remove The Screen And Keep It Aside

Step #14. Remove The Screen And Keep It Aside
Step #14. Remove The Screen And Keep It Aside2

At this stage your Google Pixel 8 Pro screen is completely free to remove it and keep it safely aside.

Step #15. Disconnect The 5G mmWave Antenna

Step #15. Disconnect The 5G mmWave Antenna

Well we are making this guide with Google Pixel 8 Pro 5G mmWave antenna model. If your phone is a non-5G mmWave antenna model you will skip the steps

  • Be very careful not to scratch or damage any of the small parts.
  • Use the spudger to carefully lift the top edge of the 5G mmWave antenna's connector.
  • Gently disconnect the cable by lifting it with the spudger.

Step #16. Give Heat For Melten The 5G mmWave Antenna Adhesive

However three pieces of strong adhesive secures the 5g mmWave Antenna.

Apply heat for just 2 minutes so that the adhesive melts.

Step #17. Remove The 5G mmWave Antenna Adhesive

Step #17. Remove The 5G mmWave Antenna Adhesive
  • Insert the flat end of the spudger between the lower edge of the 5G mmWave antenna cable and the midframe, just above the press connector.
  • Twist the spudger gently to separate the bottom of the cable from the midframe.
  • Grip the 5G mmWave antenna cable and peel it off from the midframe.
  • Remember don't try to remove it completely. At this stage it will remain in the straight-up position.

Step #18. Remove The Graphite Tape

Step #18. Remove The Graphite Tape

Here you will see a black sheet covering the entire battery. This is graphite tape. Well to finish fixing your phone you must take out and replace this graphite sheet. This sheet connects the top of the battery, the middle part of the frame, and the cameras at the back.

  • So start by sliding the pointed end of a spudger under different parts of the graphite sheet.
  • Lift gently until you can hold the sheet with your fingers.
  • The parts of the graphite sheet between the rear cameras and the battery might tear as you lift them. If they do just grab the broken piece and take it off.
  • Keep peeling until the whole graphite sheet is off.

Step #19. Move The USB‑C Cover Tape

Step #19. Move The USB‑C Cover Tape
  • Gently lift the plastic shim on top of the USB-C port cover using the pointed end of a spudger.
  • Take out the shim carefully and set it aside, or move it aside to get to the screws holding the USB-C port cover.

Step #20. Open Screws of The USB-C Port

Step #20. Open Screws of The USB-C Port
  • In your entire repair process please make sure to keep track of all the screws and remember where each screw goes.
  • Even though the Pixel 8 Pro uses special screws regular ones will still work. Just press down firmly to avoid damaging them.
  • With a T3 Torx screwdriver remove the two small screws holding the USB-C port cover.

Step #21. Remove The USB-C Cover

Step #21. Remove The USB-C Cover

Now you can remove the USB-C cover.

Step #22. Open MidFrame Screws

Step #22. Open MidFrame Screws

Well there are seven screws on the misframe.

  • Grab a T3 Torx screwdriver to take out the seven 5 mm-long 3 IP Torx Plus screws that are holding the midframe in place.

Step #23. Remove The MidFrame of The Google Pixel 8 Pro

Step #23. Remove The MidFrame of The Google Pixel 8 Pro
Step #23. Remove The MidFrame of The Google Pixel 8 Pro2

However after removing the screws you can hold it and remove it easily.

Step #24. Disconnect The Battery Cable

Step #24. Disconnect The Battery Cable

At this stage it will disconnect the battery.

  • Pry up the press connector of the battery with the help of a spudger and disconnect the power connection.

Step #25. Disconnect Front Camera And Remove

Step #25. Disconnect Front Camera And Remove

Now use the same spudger and pry up the front camera press connector. Disconnect the front camera and remove it from the frame.

Step #26. Disconnect The Rear Camera Assembly

Step #26. Disconnect The Rear Camera Assembly
  • Well at the top of the logic board you will see three rear camera press connectors.
  • Use the same pointed spudger and disconnect the rear assembly.

Step #27. Unfasten Two Screws of The Rear Camera Assembly

Step #27. Unfasten Two Screws of The Rear Camera Assembly

You might have to move the 5G mmWave antenna cable aside when removing the screws for the rear camera assembly.

  • Use a T3 Torx screwdriver to take out two screws that hold the rear camera assembly.
  • One screw, 3.5 mm long, is at the top left corner.
  • Another screw, 5 mm long, is at the top right corner.

Step #28. Remove The Rear Camera Assembly

Step #28. Remove The Rear Camera Assembly

Now insert the point of the spudger and lift the rear camera assembly.

Remove the rear camera assembly.

Step #29. Disconnect The Antenna Cable

Step #29. Disconnect The Antenna Cable

Insert one arm of a pair of angled tweezers under the metal neck of the black antenna cable. This is a coaxial connector found at the top left corner of the logic board. Gently lift straight up to disconnect the cable.

Step #30. Open Screws of the 5G mmWave Antenna Bracket

Step #30. Open Screws of the 5G mmWave Antenna Bracket
  • Use a T3 Torx screwdriver to unscrew the two 5 mm-long 3 IP Torx Plus screws holding the 5G mmWave antenna bracket in place.

Step #31. Remove The 5G mmWave Antenna Bracket

Step #31. Remove The 5G mmWave Antenna Bracket

Insert the pointed end of the spudger into a screw hole on the 5G mmWave antenna bracket. Pry gently with the spudger to loosen the bracket. Then remove the bracket.

Step #32. Separate The 5G mmWave Antenna

Step #32. Separate The 5G mmWave Antenna

Hold onto the 5G mmWave antenna cable and gently pull the antenna upward from its housing. If the cable separates from the antenna don't worry! You can simply use your fingers to lift the antenna out of place.

Step #33. Unclip The Antenna Cable

Step #33. Unclip The Antenna Cable
  • Gently remove the black antenna cable from its holders on the phone's left side and the daughterboard.
  • Carefully shift the black antenna cable away from its slot at the bottom right corner of the daughterboard.

Step #34. Open One Screw of The Google Pixel 8 Pro Earpiece Speaker

Step #34. Open One Screw of The Google Pixel 8 Pro Earpiece Speaker
  • Use a small screwdriver to remove the tiny screw that holds the earpiece speaker in place.

Step #35. Pry Up The Earpiece Speaker And Remove

Step #35. Pry Up The Earpiece Speaker And Remove
  • Insert the flat part of a spudger under the middle of the earpiece speaker's lower edge.
  • Lift the speaker carefully to take it out.
  • You may need to use a bit of force. Listen for a soft sound as the speaker comes off.

Step #36. Disconnect the Antenna Cable from the Earpiece Speaker

Step #36. Disconnect the Antenna Cable from the Earpiece Speaker
  • Put one arm of the angled tweezers under the metal neck of the black antenna cable connector near the bottom of the earpiece speaker.
  • Lift up gently to unplug the cable.

Step #37. Remove Antenna Cable Tape

Step #37. Remove Antenna Cable Tape
  • Lift the antenna cable out of the slot in the earpiece speaker.
  • Use tweezers or your fingers to remove the yellow tape.

Step #38. Separate Antenna Cable

Step #38. Separate Antenna Cable
  • Now you can pull and separate the antenna cable from its groove.
  • Apply the force carefully so that the antenna and its connection don't get damaged.

Step #39. Remove The Antenna Board

Step #39. Remove The Antenna Board

It is time to remove the antenna board from the earpiece speaker

  • There is a light adhesive holding the L-shaped antenna board under the earpiece speaker.
  • Use a spudger tool to carefully lift off the antenna board from the speaker.
  • Take out the board.

Step #40. Take The New Google Pixel 8 Pro Earpiece Speaker Replacement

Step #40. Take The New Google Pixel 8 Pro Earpiece Speaker Replacement

After removing the board you will be left with only the earpiece speaker.

Now take the new Google Pixel 8 Pro Earpiece speaker replacement.

Step #41. Attach The Antenna Board With The  New Google Pixel 8 Pro Earpiece Speaker

Step #41. Attach The Antenna Board With The  New Google Pixel 8 Pro Earpiece Speaker
  • Before you stick the antenna board to the speaker, make sure it's facing the right way, with the antenna socket matching the cable groove.
  • If your new speaker has adhesive already on it remove the covering and press the board onto the speaker.
  • If there is no adhesive on your new speaker use thin double-sided tape to attach the board to the speaker.
  • Now with very careful hands you need to set the antenna board with the new Google Pixel 8 Pro earpiece speaker.

Step #42. Paste The Antenna Cable And Clip Up



Step #42. Paste The Antenna Cable And Clip Up
Step #42. Paste The Antenna Cable And Clip Up2



  • When you know the board is perfectly set on the earpiece you can attach the black antenna cable on this board.
  • Please use the connection cable of the antenna.
  • Make sure that the connection is secure and perfectly joint.

Step #43. Place The Google Pixel 8 Pro Earpiece Speaker

Step #43. Place The Google Pixel 8 Pro Earpiece Speaker

When you are putting everything back together, tilt the side of the speaker with the orange gasket downward. Then press down firmly on the speaker until it clicks into place securely.

Step #44. Fasten One Screw of The Google Pixel 8 Pro Earpiece Speaker

Step #44. Fasten One Screw of The Google Pixel 8 Pro Earpiece Speaker
  • Now use the screwdriver that you have used for opening the screw. It is a T3 Torx screwdriver.
  • Carefully fasten the screw of the Google Pixel 8 Pro earpiece speaker.
  • Make sure the cable is back in its slot.
  • If it is not in its place it might get damaged when you put the rear camera assembly back in.

Step #45. Clip Up Antenna Cable

Step #45. Clip Up Antenna Cable

However use a pointed spudger and gently push the cable back into its clip.

Step #46. Place The 5G mmWave antenna And Connect



Step #46. Place The 5G mmWave antenna And Connect
  • It's time to reconnect the 5G mmWaves antenna.
  • Correctly press the 5G mmWave antenna connection cable.

Step #47. Place The 5G mmWave Antenna Bracket And Fasten The Screws

Step #47. Place The 5G mmWave Antenna Bracket And Fasten The Screws
  • Place the bracket by inserting it at a downward angle to make sure it touches the 5G mmWave antenna.
  • Push down firmly to secure it in position.
  • Fasten the screws.
  • Now the 5G mmWave antenna’s first connection is secured.

Step #48. Connect The Antenna Cable

Step #48. Connect The Antenna Cable

It's time to put the black antenna cable back. So you need to line it up with the socket and press down gently with the flat end of the spudger until it clicks. If it doesn't fit right away, adjust it and try again without pushing too hard.

Step #49. Place The Camera Assembly, Fasten Screws And Connect 3 connections

Step #49. Place The Camera Assembly, Fasten Screws And Connect 3 connections
  • Now place the camera assemblies back in its space.
  • Settle down the three-camera assembly.
  • Currently these rear cameras are in space.
  • Make sure to match the screw holes.
  • Now fasten the screws of the rear camera assembly.
  • After securing the rear camera assembly with screws you can connect all the rear cameras back in their sockets.

Step #50. Place the Front Camera And Connect

Step #50. Place the Front Camera And Connect

Well you have to assemble the front camera back in place.

Settle it correctly and then connect the connection cable to the logic board.

Step #51. Connect The Battery Cable

Step #51. Connect The Battery Cable
  • Carefully connect the battery cable of the Google Pixel 8 Pro.

Step #52. Place Mid Frame And Fasten All Screws

Step #52. Place Mid Frame And Fasten all Screws
  • Fasten the screws of the midframe and make it secure.
  • While putting everything back together check the thermal pad. If it's damaged, take it off.
  • Clean the area with strong alcohol and a soft cloth.
  • Then put on a new thermal pad.

Step #53. Place USB-C Port Cover And Fasten Screws.

Step #53. Place USB-C Port Cover And Fasten Screws.

Place the USB-C port cover and secure it with two screws.

Step #54. Place USB-C Cover Tape

Step #54. Place USB-C Cover Tape
  • During the reassembly process here is how to replace the plastic shim that stretches along the bottom of the midframe and loudspeaker. If you don't have a new one, just push the old one back in.
  • But if you are using the new shim tape follow the instructions.
  • Peel off the larger rectangular liner from the shim.
  • Position the shim so that the smaller foam piece aligns with the bottom of the USB-C port cover.
  • Press firmly along the entire shim using the flat end of a spudger to ensure it's securely in place.
  • Take off the remaining liner.

Step #55. Place The Grafied Sheet

Step #55. Place The Grafied Sheet
Step #55. Place The Grafied Sheet

Well you can not use the old Grafied Sheet.

  • When applying the new sheet you need to check it properly and understand its alignments.
  • Then peel off the larger clear liner from the back of the sheet to expose the adhesive.
  • Carefully place the sheet on the phone’s frame. Be very careful at this step. Because once the gratified sheet is placed it won't be removed without damage.
  • The sheet needs to be firmly secured before removing the upper liner.
  • Press down with your fingers.
  • Peel the blue liner.

Step #56. Paste The 5G mmWave Antenna

Step #56. Paste The 5G mmWave Antenna

Press the cable back onto the midframe to stick it with the old adhesive.

If it doesn't stick well use thin double-sided tape to hold it in place.

Step #57. Connect The Screen Cable And Place Its Cover

Step #57. Connect The Screen Cable And Place Its Cover
  • Position the press connector correctly over its socket.
  • Gently press down on one side until it clicks into place.
  • Repeat the process on the other side.
  • Avoid pressing down in the middle to prevent damage.
  • Misalignment could bend the pins and cause permanent harm.
  • Now install its cover back in its place.

Step # 58. Place The Screen On The Frame

Step # 58. Place The Screen On The Frame
  • Before closing up the phone, make sure it still works.
  • Turn it on briefly to check if everything is okay.
  • Then turn it off again.
  • Carefully put the screen back in place.
  • You will feel it click into position.
  • Press around the edges firmly to make sure it sticks well.
  • If you want you can press the whole phone to strengthen the hold.

Conclusion

Perfect! Now you know how to replace the Google Pixel 8 Pro Earpiece Speaker. See how simple it was.

We hope that this guide has helped in every way. Well now you can enjoy your Google Pixel 8 Pro’s earpiece speaker in its great quality. If you have any questions feel free to write to us in the comment section. It's a pleasure for us to resolve your problems. Happy repairing!

Earpiece speaker replacementGoogle pixel 8 proRepair tutorialSmartphone maintenanceStep-by-step guide

Leave a comment

All comments are moderated before being published
